This OBSTAFLASH120 ou 180 dual color medium intensity type A and B (or C) is designed for day and night marking of obstacle such as chimneys, pylons and high rise buildings (3 or more lights are required per level depending on diameter of the obstacle)

OFP-120-RW-JBL

[OBSOLETE]

Part Number 113747

The flashhead includes

2 projectors in glass and aluminium painted with 75cm of molded cable and connector
a junction box OGP-JB-6P-RW-L for 6 projectors and the connector of the power supply cable 113762
Stainless support for the 2 projectors and the junction box

Datasheet
Tender specifications
