Medium intensity type B
Replacement Product
Part Number: 113790RI-SOL-RG
OFC-RI-SOL-RG
[OBSOLETE]
Flash-head with integrated power supply
- 6 Obsta optics with cover in hard glass and aluminium base
- Simple installation with no losing parts when opening the flash-head
- 2 leds circuits main and back-up (ICAO medium intensity type B or C configuration) or simultaneously with IR
- Power supply inside the flash-head
- membrane vent
- GPS antenna included, built-in photocensor (-R) in option
Datasheet|
Main voltage
|
24VDC to 36VDC |
|
|
Average wattage
|
Below 3,5W @ 20 flashes per minute (minimum ICAO setting) |
|
IP degree
|
IP66 |
|
|
Wiring
|
Entry of cable by glands nickel plated brass and connection by terminals |
|
|
Operating temperature
|
Tu | -40/+55°C |
|
Weight
|
5 kg |
|
|
Weight
|
5kg |
|
|
Size of the light
|
220mm x 190mm x 190mm |
|
|
Cable entry diameter
|
from 7 to 13 mm |
|
|
Wire cross section
|
up to 6mm² for power supply, up to 1,5mm² for signal |
|
|
Attachment
|
4 mounting holes dia.9mm, 200mm x 140mm |
|
Standards compliance
|
ICAO annexe 14 chapter 6 (8th edition 07/2018), EASA (4th edition 2017) |
|
IR intensity and wavelength
|
|
|
|
Effective light output night mode at 0° on site
|
2000cd (red) |
|
|
Color night time
|
Red |
|
|
Vertical beam spread
|
|
|
|
Horizontal beam spread
|
360° |
|
|
Flash per minute
|
20, 30, 40 or 60 flashes per minute |
