Stainless control cabinet to be used with OBSTAFLASH OFI360-RW-048 operating during daytime only with NAVILITE 48Vdc working at night only
Replacement Product
Part Number: 113797-W-048
OFI-CAB-1E-W-048
[OBSOLETE]
- 'Weather tight' stainless steel 316L power cabinet enclosure
- Test button for day and night
- Alarm dry contact NC and NO
- Master/slave configuration for multiple lights synchronisation
- to be used with photocell 48Vdc
- in option low intensity lights NAVILITE 48Vdc for night only operation,
- wireless gps synchronisation P/N113746
Datasheet|
Main voltage
|
48VDC -10%/+15% (max current 7A) |
|
IP degree
|
IP65 in vertical position |
|
|
Operating temperature
|
Tu | -20/+45°C |
|
Weight
|
8 kg |
|
|
Size of the power supply
|
400mm (height) x 300mm (width) x 200mm (dept) |
|
|
Wire cross section
|
from 1 to 4 mm² |
