48VDC UPS Battery Backup System powered through 110 to 240VAC (or 400VAC for some application). This UPS provides battery back-up in case of main power failure for our lights powered in 48Vdc The 4 batteries remain fully charged under normal AC power

48V-BAT-12Ah-R
Part Number: 113953-R3
48V-BAT-12Ah-R
  • Metal enclosure
  • 110VAC to 240VAC power supply, 48Vdc output
  • Protection against transient overvoltage on AC and DC side
  • Protection against deep discharge batteries
  • Operating temperature -20°C/+45°C
  • 12 hours back-up for 8 NAVILITE 48Vdc series
Contact Us
Select another reference:
48V-BAT-12Ah-R
48V-BAT-18Ah-W
48V-BAT-20Ah
48V-BAT-24Ah
48V-BAT-7Ah
Nominal capacity at 25°C

12Ah (C20)
Max Power

150W
Main voltage

110VAC to 240VAC +/-10% 50/60Hz
Operating temperature
 Tu

-20/+45°C
Weight

25.5kg
Size of the power supply

500mm(height)x400mm(width)x230mm(depth)
