Remote control and accessories
NAV-CMD-48
Monitoring box allowing the control and the wiring of 2 NAVILITE 48VDC beacons, operating at night only or continuously, plugged to work simultaneously or in redundancy (a main light and a backup light working only in case the main light is not working) with remote signalization in case of failure of the light or failure of the 48VDC supply
NAV-CMD-48
Part Number
113940
Control 1 or 2 NAVILITE 48VDC either
with an active redundancy (one main lamp and one back-up lamp switched on in case of failure of the main lamp)
or a simultaneous operation of 2 lights
Control the day/night switching of the lights
Allow remote monitoring in case of lamp failure or power supply failure by potential free contact
Datasheet
User Manual
Tender specifications
Contact Us
Select another reference:
48V-NAV-CMD-120/240
48V-NAV-PW-240
NAV-BLK-12
NAV-CMD-12V
NAV-CMD-48
NAV-CMD-48-B
NAV-CMD-SOL
NAV-HI-CMD-48
NAV-JB-8
NAVILITE-CABLE-CLAMP
NAVILITE-HOLDER
NAVILITE-L810-HOLDER
SQUARE
Electrical Properties
Mechanical Properties
Main voltage
48VDC (-10%; +15%)
IP degree
IP65 in vertical position
Dimensions
160 x 58 mm
Weight
0.42 kg
Weight
300g
Cable entry diameter
6,5-12 mm & 4-10mm
Wire cross section
from 1 to 2,5 mm²
Attachment
4 screws type M4
Position of the 4 mounting holes
148 x 50 mm
Associated Products
NAVILITE-48V-CABLE
NAVILITE-48V
NAVILITE-F-48V
×
Description:
Monitoring box allowing the control and the wiring of 2 NAVILITE 48VDC beacons, operating at night only or continuously, plugged to work simultaneously or in redundancy (a main light and a backup light working only in case the main light is not working) with remote signalization in case of failure of the light or failure of the 48VDC supply
Characteristics:
- Control 1 or 2 NAVILITE 48VDC either - with an active redundancy (one main lamp and one back-up lamp switched on in case of failure of the main lamp) - or a simultaneous operation of 2 lights - Control the day/night switching of the lights - Allow remote monitoring in case of lamp failure or power supply failure by potential free contact
CITEL
Reference:
NAV-CMD-48
Part Number:
113940
Or equivalent
