Led high intensity type B - Compliant with high intensity type B according to ICAO annex 14 chapter 6 (edition July 2018) - To be used on the support of the transmission line in case it is not possible to install day warning spheres on the cables (3 levels of 2 lights on opposite side of the tower supporting power cables)
Part Number: 113780B-G-2
OFH-180-WW-048-G-2
Flashhead
- 6 led independant projectors coming with 4 meters of molded cable connected to power cabinet
- Aluminium white painted and glass enveloppe
- Stainless steel bracket
- 2 white led circuits and a red with infrared circuit inside each projector
- No losing parts and no special tools required, only 1kg per projector
Power supply
- 'Weather tight' stainless steel 316L power cabinet enclosure
- 6 independant power supplies providing a high redundancy level
- Luminous indicators for quick diagnostic
- Modular design
- Synchronisation of the flashes 1/13 2/13 & 10/13 and day/twilight/night mode through GPS
- Surge protection included
At night, this obstruction light can operates as a medium intensity type B (red flashing)
The led OBSTAFLASH180 high intensity type B is a day & night white color flashing obstruction light dedicated to transmission lines when it is not possible to install markers on the high voltage cables.
Datasheet|
Main voltage
|
48VDC -5%/+15% (max current 12A) |
|
|
Average wattage
|
120W (day time) |
|
IP degree
|
IP66 per projector |
|
|
Wiring
|
Entry of cable by glands nickel plated brass and connection by terminals |
|
|
Operating temperature
|
Tu | -40/+55°C |
|
Weight
|
20 kg |
|
|
Size of the light
|
420mm (height) x 580mm (width) |
|
|
Size of the power supply
|
400mm (height) x 300mm (width) x 200mm (dept) |
|
|
Wire cross section
|
up to 6mm² for power supply, up to 1,5mm² for signal |
|
Standards compliance
|
ICAO annexe 14 chapter 6 (8th edition 07/2018), EASA (4th edition 2017) |
|
Effective light output day time at 0° on site
|
100 000cd (white) |
|
|
Effective light output twilight mode at 0° on site
|
20 000cd (white) |
|
|
Effective light output night mode at 0° on site
|
2000cd (white) |
|
|
Color day/twilight time
|
white |
|
|
Color night time
|
White |
|
|
Vertical beam spread
|
|
|
|
Horizontal beam spread
|
360° with minimum 2 flashheads on opposite side |
|
|
Flash per minute
|
40 |
