Bird Diverter with amber light. Additional system to be used along with Obstruction light.

OFC-RA-240-RG
Part Number 113790RA-240-RG
OFC-RA-240-RG

The amber light cause visual disturbance, encouraging birds to avoid the area.

Integrated beacon including

  • 6 Obsta optical units in hard glass casing with aluminum base
  • Power supply integrated into beacon
  • Amber LED programmable in fixed or flashing mode
  • 2 independent redundant circuits
  • Surge protection included
  • Alarm dry contact in the event of lamp or power supply failure
  • Easy installation with captive elements during installation

Select another reference:
BDS-W/R/O/Y-Ø12.6/26.4
BDS-W/R/O/Y-Ø9,5/32,10
Effaroucheur
OFC-RA-048-RG
OFC-RA-240-RG

Effective light output day time at 0° on site

2000cd @ 40 flashes per minute (amber)

Effective light output night mode at 0° on site

2000cd @ 20 flashes per minute (amber)

Color day/twilight time

Amber

Color night time

Amber

Vertical beam spread

Horizontal beam spread

360°

Flash per minute

Fixed, 20, 30, 40 or 60 flashes per minute

Main voltage

110VAC to 240VAC +/-10% 50/60Hz

Average wattage

10W in flashing mode. 30W continuous light

IP degree

IP66

Wiring

Entry of cable by one cable gland and connection by terminals

Operating temperature
Tu

-40/+55°C

Size of the light

220mm x 190mm x 190mm

Weight

6kg

Wire cross section

from 1 to 2,5 mm²

Attachment

4 mounting holes dia.9mm, 200mm x 140mm
