Obstruction lighting system for high voltage lines, red fixed low intensity
Part Number: B220
Balisor B220 210KV to 360KV
The BALISOR® system comprises :
- long life cold neon discharge lamp B49 manufactured by OBSTA,
- a set of capacitive tapings in aluminium, the lenght depends on the voltage of the line to be protected,
- a set of flexible accessories for suspension and insulation which depends on diameter of the cable
The power supply by capacitive effect ensures a constant light intensity whatever is the value of the electric current crossing the line
High-voltage lines are major hazards for low-flying aircraft. Placing beacons on pylons is not sufficient to ensure safety due to the very long spans of cable (extract of Aerodrom Design Manual chapter 14.7 annex 4). The BALISOR® system (created by OBSTA in the 60's) is a beacon for high voltage lines. Its conductors take the power required directly from the line.
Datasheet|
Power source
|
Autonomous by capacitive effect |
|
|
Wattage
|
20W |
|
Attachment
|
Aluminium clamps matching with the diameter of the cable |
|
Standards compliance
|
ICAO Aerodrome Design Manual Part 4 chapter 14 |
|
Luminous intensity
|
|
